ODM Aluminum hinge with Stainless steel axis and trembled surface assembled for skylight Manufacturers, Quotes

•Pre-Drilled Holes and assembled stainless steel axis:ease of Installation: Pre-drilled holes ensure accurate alignment during assembly,
•Black Anodized Surface Finish:Provides a sleek, uniform matte or semi-gloss black appearance, ideal for modern architectural designs.Corrosion Resistance: The anodizing process creates a hard, oxide layer that protects against moisture, UV radiation, and environmental pollutants.Anodized finishes are chemically bonded to the aluminum, ensuring long-term color retention without fading, peeling, or chipping (unlike painted finishes).
•Lightweight Strength:Aluminum extrusions offer high strength-to-weight ratios, minimizing structural
•Fire Resistance:Aluminum is non-combustible (Class A fire rating), meeting stringent building safety standards.
•Recyclability:Aluminum is 100% recyclable, and anodizing is an eco-friendly process (no VOC emissions).
•Low Maintenance:The durable anodized surface requires minimal cleaning and no repainting, reducing lifecycle costs.
•Compliance & Standards:Meets international standards for curtain wall systems (e.g., ASTM, EN,Reach).

Product Description

Product Details
Product Details Image
Use: High-rise commercial buildings seeking a modern, monolithic appearance. Or projects in coastal or urban areas requiring corrosion resistance.
Material: Aluminum alloy 6063-T6 per AA standard, other aluminum alloy is also available
Dimension: around 300g/pc
Weight: 300x70x10mm or optional
Processing: Alloy melting-Extruding-cutting- machining-deburr -assemble- inspection and packing
OEM/ODM: per customer’s requirements. We can develop new products together.
Surface Treatment: Sand blasting and satin anodize or black anodize or painting or powder coating (UV proof and bear 500hours salt spray test) are also for selection
Packaging: Each pc in polybag (one end sealed),foam sheet separates each pc, 10pcs/ carton, then packed with pallet, customized packing is also available
Production Leading Time: For items per customer’s specification, mold developing and sample confirmation is 12-15 days, production leading time is 15-20 days after sample confirmed.
MOQ: 3000pcs
Supply Ability: 300000 pcs per Month
Payment Terms: 30% deposit before production, the balance paid before loading.
Port: Shenzhen or Guangzhou.
Place of Origin: China, Guangdong
Certifications: ISO9001, ISO14001, ISO45001, RCV, and GRS
Frequently Asked Questions
What are the primary applications and material specifications for this product?
This product is designed for high-rise commercial buildings requiring a modern, monolithic appearance, as well as projects in coastal or urban areas requiring high corrosion resistance. The standard material is Aluminum alloy 6063-T6 (AA standard), and other aluminum alloys can be supplied based on requirements.
What surface treatments are available?
We offer multiple surface treatments including sand blasting, satin anodize, black anodize, painting, or powder coating. Our powder coating is UV-proof and capable of passing a 500-hour salt spray test.
What is the typical lead time for production?
For custom items built to your specifications, mold development and sample confirmation take about 12-15 days. Mass production leading time is approximately 15-20 days once the sample is confirmed.
What are your packaging standards?
Each piece is placed in a single-end sealed polybag, separated with a foam sheet to prevent scratches. They are packed 10 pieces per carton and palletized for shipping. Customized packaging options are also available upon request.
What is the MOQ, supply capability, and payment terms?
The Minimum Order Quantity (MOQ) is 3,000 pieces, with a monthly supply capacity of 300,000 pieces. Payment terms require a 30% deposit prior to production, with the remaining balance due before loading.
Which ports are used for shipping and what certifications do you hold?
Shipments are typically dispatched via Shenzhen or Guangzhou ports in Guangdong, China. Our facilities and products are fully certified with ISO9001, ISO14001, ISO45001, RCV, and GRS standards.
